Outline

Traces a colored band around a node's alpha silhouette — including silhouettes a geometry stroke can't follow, like text glyphs, an image's cutout, or a whole subtree flattened together.

Outline effect demo

Usage

import { Effects } from 'motion-script';

// Default: a 4px black band outside the silhouette
<Text text={'EDGE'} effects={Effects.outline()} />

// Scalar shorthand sets the width
<Text text={'EDGE'} effects={Effects.outline(12)} />

// Full options
<Text text={'EDGE'} effects={Effects.outline({ width: 12, color: '#ff2e63', position: 'inside' })} />

// Raw object
<Text text={'EDGE'} effects={[{ type: 'outline', width: 12, color: 'red', position: 'outside' }]} />

Props

Prop	Type	Default	Description
`type`	`'outline'`	–	Effect identifier
`width`	`number`	`4`	Band thickness in pixels. Scales with the node, like a blur radius
`color`	`Color`	`'black'`	Any CSS color, theme alias, or `[r, g, b, a]` tuple
`position`	`'outside' \| 'center' \| 'inside'`	`'outside'`	Which side of the edge the band grows from
`mode`	`'foreground'`	`'foreground'`	Foreground only — a backdrop has no silhouette to trace

Choosing a position

'outside' grows beyond the edge and leaves the content untouched. Note that it needs somewhere to go: on a shape that fills its own box, or inside a clipping parent, the band lands outside the visible area.
'inside' eats inward, so the node's footprint never changes. The safe choice for a full-bleed image or a box-filling rect.
'center' straddles the edge, half the width on each side.

Animating

Both width and color interpolate, so an outline can be drawn on:

import { createScene, createRef, Text, Effects, easeOut } from 'motion-script';

export default createScene(function* (stage) {
  const label = createRef<Text>();
  stage.add(<Text ref={label} text={'EDGE'} fontSize={120} effects={Effects.outline(0)} />);

  yield* label().to({ effects: Effects.outline({ width: 14, color: 'accent' }) }, 0.6, easeOut('quad'));
});

Stacking with other effects

// Sticker look: outline the glyphs, then bloom the whole thing
<Text text={'HI'} effects={Effects.outline({ width: 10, color: 'white' }).bloom(1.5)} />

How it works

The band is the difference between a dilated and an eroded copy of the source's alpha, sampled as a ring of taps around each pixel. Two consequences worth knowing:

The tap count scales with width, so cost grows with the band — a very wide outline over a large canvas is not free.
Erosion samples rings rather than the full disc, so a feature thinner than roughly width / 12 can leak through an 'inside' or 'center' band. This shows up on hairline serifs, not on normal shapes.
